26
1 103 2020 Frame (incl. 145) 1
2 423 2026 Decal set 1
3 203 2001 Mast tube 1
4 533 2025 Nylon bushing 2
5 533 2024 Sleeve 2
6 343 2009 Axle 1
7 403 2020 Extension cable 1
8 403 2022 Connecting cable 1
9 403 2021 Reseiver 1
10 173 2020 Cover for reseiver 1
11 M3x8 DIN 965 Screw 2
12 M4x10 DIN 965 Screw 2
13 M4 DIN 127 Washer 2
14 M4x10 DIN 7985 Screw 2
15 523 2019 Sleeve 6
16 653 2009 Eye Bolt 2
17 653 2010 Cap for eye bolt 2
18 M5 DIN 125 Washer 2
38 AR01-038 Rope plate 1
40 AB02-066 Axle assy 1
41 AR01-041 Bearing housing, L(incl.128) 1
42 AR02-042 Fan blade 6
45 AR01-045 Drive pulley assy 1
47 AR01-047 Spacer 1
48 AR01-048 Bearing , R (incl.127, 128) 1
50 AR01-051 Tension spring assy 2
53 AR01-053 Rope housing 1
55 443 2010 Rope, compl. 1
56 AB01-048 Fan wheel 1
57 AB01-074 Cage, pair 1
58 AB01-075 Trim strip 1
59 AR02-059 Axle cover, pair 1
62 AR02-062 Side cover, pair 1
63 433 2015 Electr. mounting plate 1
64* RB01-032 Seat stop 2
67 AR01-067 Front stand tube 1
68 AB01-077A Sleeve 2
69 AB01-078 End cap 4
70 AR01-070 Foot 2
71 AB02-072G Transport wheel 4
72 AR01-072 Axle 4
73 AR01-073 Pulley 1
74 343 2008 Axle 1
75 203 2002 Handlebar (incl. 76) 1
76 AR02-076 Handlebar grip 2
80 103 2022 Rear stand support 1
81 AR01-081 End cap 1
82 AR01-082 Seat bracket 1
83 AR01-083 Roller 3
85 AR01-085 Washer 6
86 AR01-086 Axle 3
87* AR01-087 Nut plate 1
88 AR01-088 Pulley cover 1
89* AR02-089 Axle 1
91 103 2021 Rail (incl. 7-12, 81, 112) 1
95 AR02-095 Locking pin 1
98 AR01-098 Pedal mount assy 1
99 AR01-099 Rubber sleeve 2
101* PO R701 Pedal axle 1
102 AR01-102 Foot pedal plate, pair 1
103 AR01-103 Foot pedal assy, pair 1
105 533 2023 Nylon sleeve 6
111 233 2015 Electronics module 1
112 403 2019 Sensor + cable 1
113 AR02-113 Seat 1
115 AR01-115 Drive belt 1
127 19 DIN 471 C-Clip 1
128 17 DIN 471 C-Clip 2
129 35 DIN 472 C-Clip internal 3
130 3/16”x3/8” UNC Screw 6
131 3/16”x5/8” UNC Screw 7
136* M10 DIN 125 Washer 4
137 M4x12 DIN 7500C Screw 8
138 M3x10 DIN 7985 Screw 2
139 1/4”-20x1/2”UNC Screw 4
140* AR01-140 Screw 2
141 M8 DIN 985 Nut 3
142 1/4”-20 UNC Nut 4
143 1/4”-24 UNC Nut 2
145 M4 DIN 955 Nut clip 8
146 M4x12 DIN 7985 Screw 8
147* 3/8”-16 UNC Nut nylon 3
148* M5x15 DIN 7985 Screw 2
149* M8 DIN 127 Washer (* 8 pcs) 10
150* M8x19 ISO 7380 Screw 8
151 M6x15 DIN 7985 Screw 4
152 M6 DIN 125 Washer 4
162 M6 DIN 440 Washer 2
163 1/4”-24 UNC Nut 1
164 M5x18 DIN 7981 Screw 8
172 M5x25 DIN 7500C Screw 2
- R701A Hardware kit 1
- 583 2010 Owner’s manual 1
R710_2004 26 10.6.2004, 14:48:03
