user manual
TA-880
TA-880 user manual
Page 73
Break-out cables – NL8 mid-high
SOCAPEX PIN NUMBERS17,18,19 NOT USED
LOW/ MID-
LOW/ MID+
HIGH/MID-
HIGH/MID+
HIGH-
HIGH+
HIGH+
HIGH-
HIGH/MID+
HIGH/MID-
LOW/ MID+
LOW/ MID-
15
13
08
06
04
02
16
14
1-
1+
2-
2+
3-
3+
3+
3-
2+
2-
1+
1-
SOCAPEX PIN NO.
NL8
PIN NO.
PIN NO.
NL8
SOCAPEX PIN NO.
1-
1+
2-
2+
3-
3+
3+
3-
2+
2-
1+
1-
10
12
01
03
05
07
09
11
LOW/ MID-
LOW/ MID+
HIGH/MID-
HIGH/MID+
HIGH-
HIGH+
HIGH+
HIGH-
HIGH/MID+
HIGH/MID-
LOW/ MID+
LOW/ MID-
Extension Cables
25-way extension cables are available to order in 3, 10, 30, 50 and 100 metre lengths (EX-890)
for flying and/or remote positioning of amplifier racks. These cables utilise 2.5 mm
2
conductors for low line resistance and are black in colour to minimise visibility to the
audience.
