System Configurations
Many different system configurations of TCS series loudspeaker enclosures are possible
to suit various installation requirements, ranging from cafes, bars and restaurants to
theme parks, theatres and houses of worship. Listed below are a few common examples.
♦ Full range system for small venues
2 x TCS-59 wide dispersion enclosures
1 x TMC-750 power amplifier
♦ Full range system with sub-bass for small venues
6 x TCS-35 compact enclosures
8 x TCS-108 compact sub-bass enclosures
1 x LMS-D6 loudspeaker management system
2 x TMC-750 power amplifiers
