user manual
TCS series
tcs manual
page 7
The TCS-35
The TCS-35 The TCS-35
The TCS-35 is a compact trapezoidal passive 2-way loudspeaker
with a single 8” LF driver and a 1” titanium HF tweeter. It is
designed for background sound applications in pubs, cafes, bars
and restaurants. The cabinet is fitted with M6 internal fixings for
permanent installations using optional OmniMount 75 series,
Powerdrive 75 series and Turbosound wall and ceiling brackets.
The TCS-40
TCS-40 TCS-40
TCS-40 is a passive 2-way loudspeaker
with 2 x 8" LF drivers and a 1" HF compression
driver on a 90° x 40° horn. It can either be used
as a downfill enclosure with TCS-56 or TCS-59
arrays, or in under-balcony or delay speaker
applications. The cabinet is fitted with M10 internal steel rigging points for permanent
installations using standard eyebolts or optional Turbosound wall and ceiling brackets.
The TCS-56
TCS-56TCS-56
TCS-56 is a passive trapezoidal full range 2-way loudspeaker
with a 12" LF driver and a 1" HF compression driver on a 60° x 40°
constant directivity horn. Its controlled dispersion pattern makes
it ideal for use in main sound reinforcement arrays for houses of
worship and theatres. The HF horn can be rotated through 90°
enabling horizontal cabinet orientation. The cabinet is fitted with
M10 internal steel rigging points for permanent installations
using standard eyebolts or optional Turbosound wall and ceiling
brackets.
The TCS-59
TCS-59 TCS-59
TCS-59 is a passive trapezoidal full range 2-way loudspeaker
with a 12" LF driver and a 1" HF compression driver on a 90° x 60°
constant directivity horn. The wide dispersion pattern is ideal for
near field applications. The cabinet is fitted with M10 internal
steel rigging points for permanent installations using standard
eyebolts or optional Turbosound wall and ceiling brackets.
