Installation of a single TCS series enclosure using eyebolts
Parts required: 3 x M10 x 36mm shoulder eyebolts
3 x flat washers
3 x spring washers
1. Remove the captive countersunk bolts from the top and the rear of the cabinet using
a flat blade screwdriver.
2. Insert the shoulder eyebolts, using a flat washer and spring washer as stand-offs.
Apply a suitable thread locking compound such as Loctite 222 (see Appendix C), and
tighten as necessary.
3. Angle the cabinet as necessary using the rigging point on the back.
Installation of a single TCS series enclosure using Omnimount or Powerdrive hardware
Parts required: Omnimount or Powerdrive wall or ceiling brackets as appropriate.
1. Ensure you have the correct bracket for the intended application and weight of the
enclosure. Verify the weights of TCS series enclosures to be installed from the
technical specifications section at the end of this manual.
2. Remove the captive countersunk bolts from the rear of the cabinet using a flat blade
screwdriver.
3. Assemble the bracket to the enclosure using the bolts and hardware provided. Apply
a suitable thread locking compound such as Loctite 222 (see Appendix C), and
tighten as necessary.
