Tuthill T1050 - Assembly Clearances

Operator’s Manual 2020 0217 ENG
20
7
ASSEMBLY CLEARANCES
MODEL
GEAR END DRIVE END
SUM OF
GEAR END +
DRIVE END
INTERLOBE TIP-PORT
TIP-DOWEL
T850
0.004 – 0.009 in.
(0.10 – 0.23 mm)
0.013 – 0.018 in.
(0.33 – 0.46 mm)
0.021 – 0.022 in.
(0.53 – 0.56 mm)
0.013 – 0.017 in.
(0.33 – 0.43 mm)
0.006 – 0.010 in.
(0.15 – 0.25 mm)
0.003 – 0.007 in.
(0.08 – 0.19 mm)
T1050
0.004 – 0.009 in.
(0.10 – 0.23 mm)
0.015 – 0.020 in.
(0.38 – 0.51 mm)
0.023 – 0.024 in.
(0.58 – 0.61 mm)
0.013 – 0.017 in.
(0.33 – 0.43 mm)
0.006 – 0.010 in.
(0.15 – 0.25 mm)
0.003 – 0.007 in.
(0.08 – 0.19 mm)
