Tuthill T1050 - Parts List

Operator’s Manual 2020 0217 ENG
24
9
Assembly Drawing and Parts List
PARTS LIST
ITEM
NO.
PART DESCRIPTION STD LS*
1 Drive Rotor 1 1
2 Driven Rotor 1 1
3 Housing 1 1
4 End Plate 2 2
5 Extension Cover 1 1
6 Drive End Cover 1 1
7 Gear End Cover 1 1
8 Timing Gear Assembly
1
Set
1
Set
9 Bearings 2 2
10 Bearing 2 2
11 Bearing Shield 2 2
12
Piston/Slinger Seal
Assembly
4–
12
Piston/Lip Seal
Assembly
–4
13
Oil Slinger Drive
Assembly
11
14
Oil Slinger Driven
Assembly
11
16 Gasket 2 2
17 Drive Shaft Seal 1 1
18 O-ring Cover 2 2
19
Shur-Melt™ Plug
(LH Thread)
22
20
Blank Plug
(LH Thread)
22
21 Oil Sight Glass 4 4
22 Pipe Plug 12 12
23 Gear Key 2 2
24 Rotor Shaft Washer 3 3
25
Socket Head Cap
Screw
33
26
Socket Head Cap
Screw
16 16
ITEM
NO.
PART DESCRIPTION STD LS*
27
Socket Head Cap
Screw
16 16
28
Socket Head Cap
Screw
16 16
29 Lock Washer 32 32
30 Dowel Pin 8 8
31 Bearing Shims 8 8
32 Drive End Spacer 2 2
39**
Socket Head Cap
Screw
16 16
391** Lock Washer 32 32
40**
Pipe Plug (or Breathers
on LS model)
22
42 Shoulder Screw 2 2
43** Lock Washer 2 2
44** Hex Nut 2 2
* LS represents parts and quantities required for
the LS (lip seal) version
** Not shown on drawing
