Name & Function of Each Part
[H/V DELAY & EXT. SYNC] button/lamp
- Used when checking horizontal sync and vertical sync simultaneously.
After applying Analog sync(CLK, H, V) check whether the SYNC is corresponding with SDI,
Component, Composite modes.
[BLUE ONLY / MONO] button/lamp
- You may remove R(red) and G(green) from the input signal and play the screen only in B(blue)
signal. And if the button hit twice, it will turn to MONO mode. (This mode use only luminance
[CHROMA/PHASE/SCREEN SEL] (In Single Mode) button
- Used when changing the CHROMINANCE and PHASE values during menu in-activation. One time
of touch of the button will turn the product to CHROMA mode, and if the button is hit twice, to
automatic PHASE setting. (PHASE may be used only ANALOG mode.)
[CHROMA/PHASE/SCREEN SEL] (In Multi Mode) button
- Used to select a display in Multi Mode.
- Used when OSD menu is activated.
- Used when moving within the menus during OSD menu activation. It may also be used to control
the BRIGHT value during OSD menu inactivation.
- Used when moving within the menu during OSD menu activation. It may also be used to control
the CONTRAST value during OSD menu inactivation.
- Used when conrming a chosen value (or mode) during OSD menu activation or inactivation.
- It aords power supply, which may be indicated by indication lamp. The lamp is RED during power
supply and GREEN during system is in operation. In case of power cut and sudden shut o of the
power, the monitor keep previous setup stage.
- Used when power on and o.
- LED indicating monitors current status.
