9
LVM-171W / 241W / 401W / 461W / 571W
· DOWN/BRIGHT
Used to move within the menus during OSD menu activation. It may also be used to
control the BRIGHT value when the OSD Menu is inactive.
· UP/CONTRAST
Used to move within the menus during OSD menu activation. It may also be used to
control the CONTRAST value when the OSD menu is inactive.
· ENTER
Used to confirm a chosen value (or mode) or for shortcut access to volume control
when OSD menu is inactive.
· STANDBY
Signifies unit is connected to power source, which is indicated by power lamp. The
lamp is RED when connected to a power supply and in Standby mode. The lamp is
GREEN when monitor is on. In case of sudden power loss the last power state of the
monitor is remembered.
· POWER
Used to turn power on and off.
· TALLY
LED that can be toggled via Remote Control.
<REAR>
· REMOTE (RJ-45)
Provides connection to monitor control equipment via simple GPI contact closure.
· DVI IN / FACTORY PGM
Used to connect DVI-A or DVI-D signals
- FACTORY PGM
Factory Program port used for firmware updates and automatic alignment
