TVLogic LVM-246W User Manual

Multi Format LCD Monitor 13
● [MENU/EXIT] Button/Lamp
- Activates OSD menu.
● [ENTER/UP/DOWN] Knob
- Used to conrm a chosen value.
- Used to move the cursor in OSD menu.
● [OPERATE] Lamp
- Indicates the status of power connection and
monitor operation.
- The LED is o with power o.
- The LED is red when the monitor is in waiting
mode with power on.
- The LED is green when the monitor is
operating.
● [POWER] Button/Lamp
- Turns on or o the monitor power.
● [USB]
- Updates new rmware and color calibration.
● [AUDIO OUT] (Phone jack)
- Outputs dis-embedded audio signal, HDMI
audio signal or stereo signal from outside
through internal speaker or phone jack.
● [TALLY] Lamp
- Tally lamp that can be toggled in green or
red using the REMOTE(RJ-45) port.
3. Controls & Functions
LVM-182/232W : REARLVM-182/232W : FRONT
● [REMOTE] (RJ-45)
- Provides connection to control equipment
for external monitor control.
- Features can be changed in the [REMOTE]
section of OSD menu.
● [RS422 IN/OUT] (RJ-45)
- Controls the monitor by a protocol provided
by TVLogic or supports TSL protocol.
● [DVI-I] (DVI-I)
- Signal input terminal for DVI ANALOG or DVI
DIGITAL signal.
● [HDMI(HDCP)] (HDMI)
- Signal input terminal for HDMI signal.
● [CVBS] (BNC)
- Signal input terminal for COMPOSITE signal.
● [SDI-IN A] (BNC)
- Signal input terminal for 3G/HD/SD SDI
signal.
● [SDI-IN B] (BNC)
- Signal input terminal for 3G/HD/SD SDI
signal.
● [SDI-OUT] (BNC)
- Signal output terminal for 3G/HD/SD SDI
input signal through SDI-IN.
● [Audio in] (PHONE JACK)
- Inputs external audio.
● ~ AC IN
- 100 ~ 240V AC 50/60Hz
<WARNING!!>
When using the product make sure to ground,
whenever possible, before connecting the
input signal cable in order to prevent any
possible damage to the product or connected
devices. The damage may include signal noise,
malfunction of main board or display panel.
And the connected devices such as camera
or video source player may also be inuenced
through signal cable. Please check if the AC
power source and the power extender or
power distributor is grounded.
