10. Product Specifications
LVM-176W
LCD
Size 16.84”
Resolution 1366 X 768 (16:9)
Pixel Pitch 0.273(H) X 0.273(V) mm
Color Depth 16.7M (True 8bit)
Viewing Angle H : 178 degrees / V : 178 degrees
Luminance of white
350 cd/ m
2
(Center)
Contrast Ratio 900 : 1
Display Area 372.9(H) X 209.6(V) mm
Input Connector
1 X DVI-I DVI-IN
3 X BNC
Analog Video Input
2 X BNC SDI A/B Channel Input
1 X HDMI HDMI Input
Output
3 X BNC
Analog Output
1 X BNC SDI Channel (Active Through Out)
Input Signal
Analog Composite / S-Video / Component / RGB
3G-SDI 2.970Gbps
HD-SDI 1.485Gbps
SD-SDI 270 Mbps
DVI VESA/IBM Modes
HDMI 480i / 480p / 720p / 1080i VESA/IBM Modes
Analog Input Spec
CVBS 1.0Vpp (with Sync)
S-Video 1.0Vpp (Y with Sync), 0.286Vpp(C)
Component 1.0Vpp (Y with Sync), 0.7Vpp (Pb,Pr)
RGB 1.0Vpp (G With Sync), 0.7Vpp (B,R)
SDI Input Signal
Formats
SMPTE-425M-A/B
1080p(60/59.94/50/30/29.97/25/24/23.98/30sF/29.97sF/25sF/24sF/23.98sF)
1080i(60/59.94/50)
SMPTE-274M
1080i (60/59.94/50)
1080p (30/29.97/25/24/24sF/23.98/23.98sF)
SMPTE-296M 720p (60/59.94/50)
SMPTE-260M 1035i (60/59.94)
SMPTE-125M 480i (59.94)
ITU-R BT.656 576i (50)
Audio In Embedded Audio / Analog Stereo (Phone Jack)
Audio Out Analog Stereo (Phone Jack), Speaker (Mixed Mono)
Power DC 12/24V / AC 100~240V (50~60Hz)
Power Consumption (Approx.) 60 Watts(Max. 5A)
Operating Temperature
0℃ to 40℃ (32
℉
to 104
℉
)
Storage Temperature
-20℃ to 60℃ (-4
℉
to 140
℉
)
Main Body Dimensions (mm/inch) 427 x 310 x 90.5 (16.81 x 12.2 x 3.56)
Main Body Dimensions with stand (mm/inch) 474.2 x 327.8 x 150 (18.66 x 12.9 x 5.9)
Box Dimensions (mm/inch) 555 X 450 X 280 (21.85 X 17.72 X 11.02)
Weight 7kg / 15.4lbs
Basic Accessories AC Power Cord / Stand / Manual
Optional Accessories ND Acrylic Filter, Rack Mountable Kit, Sun-Hood, Carrying Case, V-mount
* The specication above may be changed without notice.
