TVLogic S-32P User Manual

05 MENU OPERATIONS
15
Studio Wall Monitor
[2] VIDEO
• EHS(DE-INT) MODE
- This item toggles the 4:4:4 video processing
lter On/O.
- To eliminate ringing artifacts under 4:2:2
sources, please set this Filter to ON or OFF.
• FAST MODE
- Used to minimize the time delay between
arrival of the serial electrical signal at the
monitor input and the light output from the
screen.
- Since this function is to minimize the de-
interlacing delay, it will not be eective under
progressive format.
- This function is useful when the input signal is
the fast moving video, and also useful to reduce
the delay time between the video and the audio.
• 3G FORMAT
- Used to select input format of SDI 3G A/B
support.
- The available modes are as follows.
NORMAL
MODE A 444 10BIT_YCbCr
A 444 10BIT_RGB
A 444 12BIT_YCbCr,
A 444 12BIT_RGB
A 422 12BIT_YCbCr
B 444 10/12BIT_YCbCr
B 444 10/12BIT_RGB
B 422 12BIT_YCbCr
B 422 10BIT_YCbCr 50/60P
- Automatically detect the signal when the
payload signal appears in NORMAL mode.
• VIDEO RANGE SELECT
- Used to set the VIDEO RANGE of input signal.
- Available modes are [NARROW] and [FULL].
• TIME CODE ENABLE
- Used to display the Time Code.
- Available modes are [OFF], [VITC] and [LTC].
• BLUE ONLY
- Used to remove red and green from the input
signal and display the screen only under a blue
signal.
- Available modes are [OFF], [BLUE], [MONO].
• H/V DELAY
- Used to check the Ancillary (ANC) data.
- Available modes are [OFF] and [ON].
• H FLIP (Not supported)
- Used to ip the displayed image horizontally.
• V FLIP (Not supported)
- Used to ip the displayed image vertically.
EHS(DE-INT) MODE
Video & Display
Closed Caption
FAST MODE
3G FORMAT
VIDEO RANGE SELECT
TIME CODE ENABLE
CC INFO
DECODE CHANNEL(608)
CAPTION SERVICE(708)
TELETEXT PAGE
BLUE ONLY
H/V DELAY
V FLIP
H FLIP
CLOSED CAPTION
S-46P
OFF
OFF
NORMAL
FULL
OFF
OFF
OFF
OFF
OFF
ANC(608/708)
CC608(ANC)
CC 1
Service 1
101
