TVLogic XVM-175W User Manual

Multi Format LCD Monitor 11
3. Controls & Functions
FRONT : XVM-325W
 [VIDEO] lamp
- Used when COMPOSITE INPUT is selected.
 [S-VID] lamp
- Used when S-VIDEO INPUT is selected.
 [COMP] lamp
- Used when COMPONENT INPUT is selected.
 [RGB] lamp
- Used when RGB INPUT is selected.
 [DVI-A] lamp
- Used when DVI ANALOG INPUT is selected.
 [DVI-D] lamp
- Used when DVI DIGITAL INPUT is selected.
 [HDMI] lamp
- Used when HDMI INPUT is selected.
 [SDI-A] lamp
- Used when SDI-A INPUT is selected.
 [SDI-B] lamp
- Used when SDI-B INPUT is selected.
 [ANALOG] button/lamp
- Used to select desired Analog Input. Press
the button to activate the analog input
menu selection, then use UP and DOWN
button to select desired input.
 [SDI-A] button/lamp
- Used to select SDI-A input.
 [SDI-B] button/lamp
- Used to select SDI-B input.
 [PBP] button/lamp
- Used to select PBP(Picture-by-Picture) function.
 [F1] (In Single Mode) button/lamp
- This Functions button is used to activate the
feature selected in “System- KEY FUNCTION
1 ” menu.
 [F1](In Multi Mode) button
- Used to select a display in Multi Mode.
 [F2] button/lamp
- This Functions button is used to activate the
feature selected in “System- KEY FUNCTION
2 ” menu.
 [F3] button/lamp
- This Functions button is used to activate the
feature selected in “System- KEY FUNCTION
3 ” menu.
 [F4] button/lamp
- This Functions button is used to activate the
feature selected in “System- KEY FUNCTION
4 ” menu.
