Multi Format LCD Monitor 7
3. Controls & Functions
XVM-175W : FRONT
XVM-175W : REAR
RS 232
REMOTE
RS422 IN
RS-422 OUT
HDMI
LAN
AUDIO IN
DC 12V IN~AC IN
CVBS1/Y/G/S-Y
CVBS2/Pb/B
CVBS3/Pr/R-S-C
DVI-I
SDI-A
SDI-B
EXT.SYNC
