Multi Format LCD Monitor 9
FRONT : XVM-175W
3. Controls & Functions
 [F1] (In Single Mode) button/lamp
- This Functions button is used to activate the
feature selected in “System- KEY FUNCTION
1 ” menu.
 [F1](In Multi Mode) button
- Used to select a display in Multi Mode.
 [F2] button/lamp
- This Functions button is used to activate the
feature selected in “System- KEY FUNCTION
2 ” menu.
 [F3] button/lamp
- This Functions button is used to activate the
feature selected in “System- KEY FUNCTION
3 ” menu.
 [F4] button/lamp
- This Functions button is used to activate the
feature selected in “System- KEY FUNCTION
4 ” menu.
 [F5] button/lamp
- This Functions button is used to activate the
feature selected in “System- KEY FUNCTION
5” menu.
 [MENU/EXIT] button
- Used to activate the OSD menu.
- When the OSD menu is activated, press this
button to exit from the menu.
 [UP/DOWN/ENTER] Knob
- Used to move within the menu when OSD
menu is activated and is also used to
decrease or increase the value of the
selected feature.
- Press the knob to select the main menu and
sub menus.
- When OSD menu is inactivated, press
the knob to adjust the value of Volume,
Brightness, Contrast or Aperture.
 [ENTER] button
- Used to conrm a chosen value (or mode).
It may also be used to control the VOLUME
value during OSD menu inactivation.
 [TALLY] lamp
- LED indicating monitors current status.
 [USB]
- The USB port for easy rmware updates.
 [PHONE JACK]
- Used to Stereo Audio Output through Phone
Jack.
