All the eight bars will be displayed when the fuel in
the tank reaches above 9 litres (full tank). When the
fuel reaches half tank (6.5 litres approx.), the fuel
gauge displays only four bars as shown.
The fuel gauge shows only single bar when the fuel
reaches reserve level (3.3 litres approx.)
This single bar starts blinking when the fuel reaches
to the minimum safe level 2.5 litres approximately.
Once the fuel level reaches 2 litres approximately, no
bar will be visible and the low fuel indicator (seriel no.
2) starts glowing continuously.
If all the fuel level bars in the cluster are blinking
contact nearest TVS Motor Company Authorised
Main Dealer / Authorised Dealer.
If the battery is disconnected and reconnected during
service. You may need to reset the time as explained in
page No. 23.
8. Turn signal indicator ( )
Flashes when the ‘left’ or ‘right’ side turn signal
indication is activated.
9. Digital clock
Digital clock indicates the time in 12 or 24 hour time
format. Refer page No. 23 for changing the time
format and setting the clock time.
10. Fuel gauge
Digital bars indicates the approximate quantity of
fuel available in the fuel tank. There are eight bars to
indicate the quantity of fuel available in the tank.
