LOCATION OF PARTS - VEHICLE FRONT & REAR
FRONT
1. Position lamps
2. Head lamp
3. Head lamp focus adjuster
4. Turn signal lamp front LH
5. Turn signal lamp front RH
6. License plate front*
7. Throttle cable adjuster
REAR
1. Fuel tank cap
2. Turn signal lamp rear RH
3. Tail / brake lamp
4. Licence plate rear*
5. Transmission oil level screw
6. Reflex reflector
7. Turn signal lamp rear LH
KNOW YOUR TVS JUPITER
KNOW YOUR TVS JUPITER
-10-
2
4
5
6
7
1
1
2
4
5
6
3
7
* Mandatory accessory will be charged extra
