TVS Jupiter User Manual

MAINTENANCE
-41-
MAINTENANCE
Warning
Warning
Always make sure that whenever the wheel is
removed, axle nut is properly re-tightened to the
specified torque.
The exhaust system becomes hot after a run. Park
the vehicle in a place where pedestrians or children
are not likely to touch the vehicle.
Caution
Do not park the vehicle on a slope or soft ground or
else it may fall down.
During storage, the battery must be recharged at
recommended charger if stored more than a
month.

TVS Jupiter Specifications

General

Engine Type	Single Cylinder, 4 Stroke, Air Cooled
Displacement	109.7 cc
Front Suspension	Telescopic Hydraulic
Kerb Weight	109 kg
Tyre Type	Tubeless
Transmission	CVT
Wheelbase	1275 mm
Ground Clearance	150 mm
Seat Height	765 mm
Starting System	Electric Start & Kick Start
Brakes	Drum (front), Drum (rear) / Disc (front), Drum (rear) for higher variants
Headlamp	LED
Fuel Tank Capacity	6 liters
