MAINTENANCE
MAINTENANCE
-29-
Item In free service After free service
Service 1st 2nd 3rd 4th 5th Remarks
Every Every
km 500- 750 2500-3000 5000-6000 8500-9000 11500-12000
3000 km 6000 km
Period from the date of sale 1 month 3 months 6 months 9 months 12 months
Speedometer gear pinion / cable – – L – L – L Lubricate using grease
Front fork oil – – – – – – – Replace every 24000 km
All fasteners I & TI I & TI I & TI I & TI I & TI I & TI –
All bulbs, horn and switches I I I I I I – Inspect for proper functioning
Head lamp beam I & A I & A I & A I & A I & A I & A –
Battery electrolyte level I & T I & T I & T I & T I & T I & T –
5
Specific gravity and voltage I I I I I I –
Brake effectiveness / play I & A I & A I & A I & A I & A I & A –
Brake cam – – C & L – C & L – C & L Lubricate using grease
Wheel freeness I I I I I I –
Front wheel bearing – – – – L – – Lubricate using grease
every 12000 km
Tyre pressure at cold condition I & S I & S I & S I & S I & S I & S –
Engine idling RPM I & S I & S I & S I & S I & S I & S –
6
Idling CO% I & S – – – – – –
Centre / side stand pivot L L L L L L – Lubricate using TRU4 oil
Kick starter pedal pivot L L L L L L – Lubricate using TRU4 oil
R - Replace; I - Inspect; T - Top up; C - Clean; A - Adjust; DR - Drain; L - Lubricate; TI - Tighten; S - Set
1 2 3
Inspect for damage Clean and adjust every 12000 km after first service Clean the cover with air. Lubricate kick starter with grease
4
5
Inspect for proper operation and adjust play. Lubricate ends using grease Recharge if necessary
6
Idling CO% should be set with the help of exhaust gas analyser and tachometer only
