SPRAY MASTER

®

MIG GUN

English

Français

Español

AIR-COOLED

250 AMP

350 AMP

450 AMP

SAFETY AND

OPERATING

INSTRUCTIONS

Revision: AC Issue Date: 9-2016 Manual No.:

89200009

Table of Contents

Questions and Answers:

E
Erin MannAug 2, 2025
Why is my Tweco Welding System MIG gun running hot?
- L
  Lori WilsonAug 2, 2025
  If your Tweco Welding System's MIG gun is running hot, it could be due to several reasons. First, check for loose contact tips or diffusers and tighten them securely. Inspect the entire gun for any loose power connections and repair them as needed. Also, examine the ground cable or clamp for looseness or undersizing, and tighten or replace them if necessary. Finally, ensure that you are not operating the gun above its recommended amperage rating; readjust the machine to the correct setting for the gun size you are using.
M
martin23Aug 12, 2025
How to fix inconsistent wire feed on my Tweco Spray Master?
- G
  Gabrielle RandolphAug 12, 2025
  Inconsistent or non-smooth wire feed in your Tweco Welding System can stem from several causes. Start by tightening any loose contact tips or diffusers. If the contact tip is excessively worn, replace it. Clean or replace the contact tip if there's spatter buildup. Straighten or replace the conduit if there are sharp bends or kinks. For a dirty or plugged conduit, replacement is necessary. Ensure the conduit is correctly positioned against the diffuser and the front set screw is tight. If the issue persists, reset the machine according to the recommendations from the machine and wire manufacturers.

Tweco Spray Master Series Specifications

General

Spray Pattern	Adjustable
Weight	Varies by model
Application	Welding
Nozzle Size	Varies by model
Hose Length	Varies by model

Summary

SECTION 2: SAFETY PRECAUTIONS

SECURITY MEASURES

Essential safety measures, warnings about injury or death, and general precautions for welding equipment users.

SECTION 3: MIG GUN SPECIFICATIONS

DUTY CYCLES

Duty cycle ratings for different MIG Gun models (250, 350, 450 AMP) under various operating conditions.

SECTION 4: MIG GUN INSTALLATION

DIRECT PLUG MIG GUN INSTALLATION

Step-by-step guide for installing direct plug MIG guns into wire feeder outlets, including control wire connections.

TWECO MIG-KWIK CONNECTION AND ADAPTER KIT INSTALLATION

Instructions for installing TWECO MIG guns using MIG-Kwik connections and adapter kits with wire feeders.

SECTION 6: REPLACE CONDUCTOR TUBE

SECTION 7: WIRE CONDUIT REPLACEMENT

CONDUIT REMOVAL

Detailed steps for safely removing the wire conduit from the MIG gun assembly.

CONDUIT INSTALLATION

Procedures for installing a new wire conduit, including cutting to length and securing.

REPAIR OF CABLEHOZ®

SECTION 8: MAINTENANCE AND TROUBLESHOOTING
