Rev: 2012.04.23a 17
Motor Mount
Prep the surface to be glued. Use medium
grit sand paper, clean with alcohol
Using Welders’ glue, evenly coat the
prepped side of the motor mount and the
mating area on the nose of the fuselage.
Let sit for 1 minute before attaching
Press and hold in place for a minimum of
1 minute. Allow to dry
Allow to dry Allow to dry
Allow to dry thoroughly before
thoroughly before thoroughly before
thoroughly before
attaching motor
attaching motorattaching motor
attaching motor.
..
.
Install the motor using the provided
hardware in such a way that the wires will
be on the same side as you have chosen to
mount the ESC. Prop is installed by
placing the propeller onto the shaft and
then looping the o-ring on one of the
screws, over the prop hub and onto the
other screw.
Side Force Generators
Slit along the cut-out as shown, coat with
Welders and position into the slots on the wing,
repeat for the other side
