TWM EXTRA 330L 60 - Page 10

PWA2.3x8mm Screw
6
6
d1.5 x D6.5 mm
Silicon Grommet
d2.5xD8mm Washer
2
2
PM2.5x25mm Screw
Canopy & Pilot
16
3
Main Wing
15
P.9
Self Tightening Wing Latch
PWA2x12mm
Wing Tube
PWA2.3 x 8mm
Silicon Grommet
d1.5 x D6.5 mm
PM2.5x25mm
d2.5xD8mm
Washer
Pilot
First insert the grommet to the canopy then apply screw.
Plastic
Plate
A156SPO25891108
