TWM EXTRA 330L 60 - Aileron Servo

Main Wing
1
Aileron Servo
2
Bottom View
6
PB2x25mm Screw
8
PWA2x8mm Screw
Fuel Tube
Ø6x5mm
PB2x25mm
Tri-horn
M3x14mm
Clevis
Pushrod
Ø1.8x120mm
Fuel Tube
Ø6x5mm
Straper
PWA2x8mm
1 m m
PWA2 x 8mm
Aileron Servo Lead
Bottom View
P.3
Ø1mm pilot holes for World Models tri-horn are pre-drilled.
Please look for pin-hole marks at under side of control surfaces.
Apply instant type CA gule to both sides of each hinge.
