TWM EXTRA 330L 60 - Radio Equipment

Ins tal l a nd a rra nge the s erv o a s show n in the d iag ram .
14
Cowling
Spinner
First insert the grommet to the cowling then apply screw.
d1.5 x D6.5mm Silicon Grommet
PWA2.6X 12mm Screw
4
4
P.8
Sponge
Front
Throttle Servo
Elevator Servo
Throttle Pushrod
1.2x350mmØ
Elevator Pushrod
F45B
F44A
F45C
F44A
F45C
F43
F43
F45B
PWA2.6x12mm
d1.5xD6.5mm
Silicon Grommet
Rudder Pullwire
Ø1x700mm
Rudder Servo
Elevator Pushrod
F43
F45A
Please refer to the
attached sheet for
usage of the
transparent 3D
template.
Servo Set
12
3 x 3mm Set Screw
Linkage Stopper
M2 Nut
2mm Washer
1
1
1
2
Pushrod Connector
Elevator Servo
Press down the center
1/3 portion
Copper Tube
KM 2x8mm
2mm
Elevator Pushrod
Ø1.8x100mm
F45
F44
Radio Equipment
13
Please refer to the attached sheet for linkage connector installation.
Throttle Pushwire
3mm
Throttle Servo.
2mm
2mm
Washer
M2 Nut
2mm
Washer
1.5mm
J2(Pushrod Ø1.8x600)
J1(Pushrod Ø1.8x100)
J1
J2
A156SPO25891108
