TWM EXTRA 330L 60 - Fuel Tank

Completed
10
Fuel Tank
11
Engine
8
M4 Nut
d4xD9mm Washer
4
8
2x93.8x120mm
Plywood
M4x30mm
d4xD9mm
Washer
M4 Nut
135mm
5.32in.
Throttle Pushwire
.Ø1 2x350mm
Plastic Tube
d2xD3x140mm
IIIustration is for inverted
mounting. You can mount
the engine upright or
sideways simply by rotation
the engine mount. Thrust
angles will not be affected.
P.7
Fuel Tank
380cc
UP
M4x30mm Socket Head Screw
Double-sided Tape
40x100mm
Cable Tie
1.5x5x400mm
1
2 3
A156SPO25891108
