TWM EXTRA 330L 60 - Tail Landing Gear

Apply instant type CA glue to
both sides of each hinge.
Stabilizer Elevator &
3
Apply instant type CA glue to
both sides of each hinge.
A=A
A
A
Completed
(Stabilizer)
(Main Wing)
B
B'
B
B
Temporary install the main wing, adjust leveling
of the stabilizer to make it as parallel to the main
wing as possible.
C=C'
C
C
Completed
5
Tail Landing Gear
2.1mm Collar
2
PA3 x 12mm Screw
2
M3 x 3mm
Set Screw
PA3 x 12mm
2.1mm Collar
Bottom View
P.4
1.5mm
2.1mm
