Designation Characteristics
AMP/LINEOutput
Jack 6.35mm (1/4”) balanced (TRS)
Impedance: 470 Ohms
OUT LEVEL switch sets the output level.
AMP:
Maximum output level:
• (no load, balanced): 10.7 dBu
• (10k Ohms load, balanced): 10.5 dBu
• (no load, unbalanced): 4.7 dBu
• (10k Ohms load, unbalanced): 4.2 dBu
Line:
Maximum output level:
• (no load, balanced): 16.5 dBu
• (10k Ohms load, balanced): 16 dBu
• (no load, unbalanced): 10.5 dBu
• (10k Ohms load, unbalanced): 10 dBu
Noise: less than -94 dBu from 20 Hz to 20 KHz
Headphones Output Jack 6.35mm (1/4”) stereo (TRS)
ADC
Minimal full-scale input level: 4.7dBu (GTR), 10.3dBu(LINE)
Sampling frequency: 96 KHz
Resolution: 24 bits
Signal to noise ratio: 100 dB
DAC
Sampling frequency: 96 kHz
Resolution: 24 bits
Noise level: -105 db
Frequency response (-1db) 12 Hz - 19 kHz
Latency 1.7 ms (Line Input to Line Output)
Power supply
Mains power adaptor DC Jack 2.1mm, negative center
Input voltage: 12V DC
Power: approx. 3.6 W
Current draw: 300mA
Dimensions
Width: 178mm
Depth: 120mm, 128mm including connectors
Height: 37mm, 58mm including knobs
Weight: 750 g
7 Technical support
Should you encounter a problem with your product or need help regarding any technical aspects,
please note that Two notes Audio Engineering has developed on-line services to provide you with fast
and efficient technical support, the Two notes Help Desk.
Don't hesitate to browse the Knowledgebase, which contains all sorts of useful informations, or submit
a ticket if you have any question or need assistance with a Two notes product.
