Part 5
Configuring and using the TORPEDO Live
1 The TORPEDO Live interface
The TORPEDO Live parameters are organized in menus, accessible by different push-buttons and
knobs you will see on the figure 3.1:
• Two 2-function rotary encoders: PRESET/PARAMETER, OUTPUT LEVEL/VALUE
• Two push-buttons: SETUP and EDIT/HOLD TO SAVE.
• One potentiometer: input gain.
When pushing a button or turning an encoder, you see a parameter moving on the two lines
display (item 3 in figure 3.1).
2 Input gain control
This encoder controls the input gain of the unit. As the TORPEDO Live being a digital product, it
is absolutely critical to avoid any saturation of the input signal and avoid the risk of considerably
reducing the audio quality. The input level is controlled by a potentiometer and is the same for all
presets. To get the best sound, try to have the same volume (or close) on all different sounds coming
to the TORPEDO Live. This way you won’t have to change the input gain when switching the channels
on your amplifier. If you don’t have individual volume settings on your amplifier channels, always do
the gain setting with the loudest channel.
The input gain adjustment must be done with input signal present at the input selected (speaker or
line input). The input bargraph gives you a visual indication of the input signal amplitude. The upper
red led is on when there is saturation in the input stage: lower the volume of your amplifier output
and/or lower the input gain.
For optimum quality, we advise to keep the peak levels of the input
signal at a maximum of -12dB to -6dB on the bargraph.
3 Three modes: PERFORM, EDIT & SETUP
The TORPEDO Live has three different mode, giving you access to different parameters:
Two Notes Audio Engineering TORPEDO Live 18
