Specifications
Designation
Characteristics
S/PDIF
Sampling frequency: 48 KHz or 96 KHz
Master only, no external synchronization
Wet signal on left channel, dry signal on right channel
ADC
Gain controlled by analogue potentiometer, -inf to 0dB
Minimal full-scale input level: -2.8 dBu (Line Input)
Sampling frequency: 96 KHz
Resolution: 24 bits
Signal to noise ratio: 100 dB
DAC
Sampling frequency: 96 KHz
Resolution: 24 bits
Signal to noise ratio: 105 dB
Frequency response (-1db)
5 - 19 KHz
Latency
2.875 ms (Line Input to Line Output)
Thermal security
Temperature controlled fan
At 100°C, a visual warning is displayed and -12 dB attenuation is applied on the signal
At 110°C, the loadbox is disconnected, the amplifier sees a 220 Ohms security load, and
signal is muted.
Power supply
IEC60320 C14 power connector
Input voltage: 85-264 V AC, 47-63 Hz
Power: approx. 10 W
Dimensions
Width: 430mm, 483mm including rack-mounting edges
Depth: 163mm, 182mm including connectors and knobs
Height: 44mm
Weight: 2 kg
Two Notes Audio Engineering TORPEDO Live 34
