Part List
2
Hexagonal wrench*5 TF card*1 Card reader*1 Polypropylene sheet*1 ER-11 6MM collet*1
Cable Tie Mount*2
Wifi antenna*1 Nylon tie*14 Motor protection cover + motor cable V Bit*1
Mill cutter*1
Straight cut*1 30 degree carving cutter*10 M5X50 self-tapping screw*8
M5X8 screw*10
M3X5 screw*2
M3X16 screw*2
M5X12 screw*2
1. Z-axis motor
2. T8-4 Screw
3. 775 spindle motor
4. 4080U side profile
5. Sheet metal side panel
6. USB interface
7. TF card slot
8. Emergency stop switch
9. TS35 touch screen
10. Engraving platform
11. M5 Calibration screw
12. X-axis motor
13. Y-axis Limit switch
14. X-axis Limit switch trigger
15. Z-axis Limit switch
16. M6 fixed hole
17. Clamp
18. Rubber feet
19. X-axis support plate
20. Y-axis motor
Know Your CNC Machine
3
①
②
③
④
⑤
⑥
⑦
⑧
⑨
⑩
⑪
460x460x80mm working space, creating more possibilities to meet most daily needs
Cup head M5X20 screw*4Cup head M5X12 screw*2
⑫
⑬
⑯
⑰
⑱
⑲
⑳
⑮
⑭
Cup head M5X50 screw*2
