12
TRACTOR SELECTION
Tractor Specifications
TE480 – Tractor size must
be a minimum of 45kW (60 HP) – 3000kg
Tractors must be equipped with a power take off (PTO) shaft that must run at 450 rpm
during operation. The PTO shaft should run clockwise when viewed from the rear of the
tractor and ideally be of a 1⅜” S.A.E. – 6 spline shaft type to enable a standard PTO shaft
to be connected.
The tractor should have counterbalance weights (on approved mountings) fitted if
necessary and/or ballasted wheels to ensure stability of the unit at all times.
Stability may be further increased with a wider track setting on the tractors rear wheels –
contact your local dealer or tractor agent for specific advice on this subject.
Four wheel drive tractors have extra weight inbuilt plus larger front wheels, this is an
advantage in keeping the unit stable.
TRACTOR/OPERATOR GUARDING
Use a tractor with ‘safety glass’ windows if possible and fit Operator guard (Part
No.7313324) using the hooks provided.
Shape ‘safety protection material’ to cover all vulnerable areas. Remember the driver must
be looking through ‘safety protection’ at the flail head in any
working position.
If the windows are not laminated safety glass polycarbonate glazing must also be fitted.
If the tractor has a roll bar only, a frame must be made to carry both mesh and
polycarbonate glazing.
Ensure the operator is guarded by ‘safety protection’ whatever position the machine is in
and that the protection is such that it does not interfere with tractor and machine functions
or obstruct the operator’s vision.
