180°
Note: After clamping into the slot, tighten the screws.
After tightening, the long side of the T-nut should be parallel to the horizontal plane.
注意： 卡入槽中后，再拧紧螺钉。拧紧螺丝后，T型螺母的长边应与水平面平行
5
5. Install The Triangle Aluminum 安装三角铝件
Triangle Aluminum
三角铝件
x4
T-nut T型螺母
x8
M4*8 Screw 螺丝
x8
SP-5 8TWOTREES
