Jumper/Connector Function
J9 (TYFP1) Standard Front Panel Connector
J16 BMC I
2
C Bus Header
J34 USB Front Panel Header (blue)
J18 COM2 Connector
J24 PSMI Connector
J6 Chassis Intrusion Header
J35 CPLD JTAG Header
USB3 Type-A USB Connector
J33 ICH SGPIO Header
J15 Port 80 Header
J41/J42/J43/J44/J45 8-pin 4096 Fan Connector
J2/J8/J36/J37/J38 4-pin Fan Connector
J39/J40 Reset Switch/Power Switch
J3
LSI 1068E Enable/Disable Jumper
Pin 1-2 closed: Enable (Default)
Pin 2-3 closed: Disable
J7
BMC Reset Jumper
NC: Default
Pin 1-2 closed: Disable BMC
JP3
Clear CMOS Jumper
Pin 1-2 closed: Normal (Default)
Pin 2-3 closed: Clear
JP1/JP2
COM2 Switch Jumper
Pin 1-2 closed: SIO to COM2 (Default)
Pin 2-3 closed: BMC UART2 to COM2
JP4
LSI 1068E Device ID Select Jumper
Pin 1-2 closed: (Default)
Pin 2-3 closed: Device ID bit [0]=0b1
