3.2.2.1 Primary IDE Master Sub-Menu
BIOS Setup Utility
Main Advanced PCI/PnP Boot Security Chipset Exit
Primary IDE Master
Device: Not Detected
Type
LBA /Large Mode
Block (Multi-Sector Transfer)
PIO Mode
DMA Mode
S.M.A.R.T.
32 Bit Data Transfer
[Auto]
[Auto]
[Auto]
[Auto]
[Auto]
[Auto]
[Enabled]
Selects the type of
device connected to the
system.
← → Select Screen
↑↓ Select Item
+/- Change Option
Tab Select Field
F1 General Help
F10 Save and Exit
ESC Exit
Feature Option Description
Primary IDE Master
Auto
Not Installed
CD/DVD
Type
ARMD
Selects the type of device connected
to the system.
Auto
LBA/Large Mode
Disabled
Auto: Enabled LBA Mode if the
device supports it and the device is
not already formatted with LBA
Mode disabled.
Disabled: Disabled LBA Mode.
Auto
Block (Multi-Sector Transfer)
Disabled
Disabled: The Data transfer from
and to the device occurs one sector
at a time.
Auto: The Data transfer from and to
the device occurs multiple sectors at
a time if the device supports it.
Auto
PIO Mode
0~4
(at 1 interval)
Selects the PIO Mode. Select Auto
to enhance hard disk performance
by optimizing the hard disk timing.
DMA Mode Auto
Selects DMA Mode.
Auto: Auto detected.
Auto
Disabled
S.M.A.R.T.
Enabled
S.M.A.R.T (Self-Monitoring Analysis
and Reporting Technology) is a
utility that monitors your disk status
to predict hard disk failure.
Enabled
32Bit Data Transfer
Disabled
Enables 32-bit to maximize the IDE
hard disk data transfer rate.
