3.2.6.1 AHCI Port0/Port1/Port2/Port3/Port4/Port5 Sub-Menu
BIOS Setup Utility
Main Advanced PCI/PnP Boot Security Chipset Exit
AHCI Port0
Device: Not Detected
SATA Port0
S.M.A.R.T.
[Auto]
[Enabled]
Select the type of device
connected to the
system.
← → Select Screen
↑↓ Select Item
+/- Change Option
F1 General Help
F10 Save and Exit
ESC Exit
Feature Option Description
AHCI Port0 Configuration
Auto
SATA Port0
Not Installed
Select the type of device
connected to the system.
Enabled
S.M.A.R.T.
Disabled
S.M.A.R.T (Self-Monitoring
Analysis and Reporting
Technology) is a utility that
monitors your disk status to
predict hard disk failure.
