TYAN S7012 - Page 54

54
http://www.tyan.com
SDR Monitoring Next Page
Sensor Name Read only
No Sensor
Available
Sensor Event Status
Not Available
Read only
Sensor ID#
See the ID#
Index table below
Key in Sensor ID# and press [Enter] key
to retrieve Sensor Name and Sensor
Event Status.
Sensor Event Switch
See the dialog
box below
Press [Enter] key to switch between
options Available/Not Available. Select
[OK] to confirm the switch.
Main Advanced PCI/PnP Boot Security Chipset Exit
ID# NAME READING STATUS
01
02
03
04
0B
0C
0D
0E
0F
20
21
22
23
24
25
26
27
CPU0 (PECI)
CPU1 (PECI)
DIMM0 Area (RT3)
PCI Area (RT2)
CPU0 VCORE
CPU1 VCORE
3.3V
+12V
VBAT
Sys. 1 (CPU0)
Sys. 2 (CPU1)
Sys. 3 (Front 1)
Sys. 4 (Front 2)
Sys. 5 (Rear 1)
Sys. 6
Sys. 7
Sys. 8
: xx
o
C
: xx
o
C
: xx
o
C
: xx
o
C
: x.xxx V
: x.xxx V
: x.xxx V
: x.xxx V
: x.xxxvV
: xxxx RPM
: xxxx RPM
: xxxx RPM
: xxxx RPM
: xxxx RPM
: xxxx RPM
: xxxx RPM
: xxxx RPM
xx
xx
xx
xx
xx
xx
xx
xx
xx
xx
xx
xx
xx
xx
xx
xx
xx
SDR Monitoring Next Page
← → Select Screen
↑↓ Select Item
+/- Change Option
Tab Select Field
F1 General Help
F10 Save and Exit
ESC Exit
Main Advanced PCI/PnP Boot Security Chipset Exit
ID# NAME READING STATUS
28
29
Sys. 9
Sys. 10
: xxxx RPM
: xxxx RPM
xx
xx
Select [OK] to switch Available/Not Available
[OK] [Cancel]
