Memory Population Table
Single CPU Installed
(CPU0 only)
Quantity of memory installed
1
2
3
4
5
6
7
8
P0_MC0_DIM_CH_A0
√
√
NOT Re-
commended
√
NOT Re-
commended
√
NOT Re-
commended
√
P0_MC0_DIM_CH_B0
√
√
P0_MC1_DIM_CH_C0
√
√
√
P0_MC1_DIM_CH_D0
√
P0_MC2_DIM_CH_E0
√
√
√
√
P0_MC2_DIM_CH_F0
√
√
P0_MC3_DIM_CH_G0
√
√
√
P0_MC3_DIM_CH_H1
√
Dual CPU Installed
(CPU0 and CPU1)
Quantity of memory installed
2
4
6
8
10
12
14
16
P0_MC0_DIM_CH_A0
√
√
NOT Re-
commended
√
NOT Re-
commended
√
NOT Re-
commended
√
P0_MC0_DIM_CH_B0
√
√
P0_MC1_DIM_CH_C0
√
√
√
P0_MC1_DIM_CH_D0
√
P0_MC2_DIM_CH_E0
√
√
√
√
P0_MC2_DIM_CH_F0
√
√
P0_MC3_DIM_CH_G0
√
√
√
P0_MC3_DIM_CH_H1
√
P1_MC0_DIM_CH_A0
√
√
√
√
√
P1_MC0_DIM_CH_B0
√
√
P1_MC1_DIM_CH_C0
√
√
√
P1_MC1_DIM_CH_D0
√
P1_MC2_DIM_CH_E0
√
√
√
√
P1_MC2_DIM_CH_F0
√
√
P1_MC2_DIM_CH_G0
√
√
√
P1_MC2_DIM_CH_H0
√
