Chapter 1: Instruction
1.1 Congratulations
You have purchased the powerful TYAN
®
S7120 motherboard, based on the Intel®
C621A Lewisburg chipset. The S7120 is designed to support Intel
®
3rd Gen Intel
Xeon Scalable Families, and Up to 1,024GB RDIMM/ 2,048GB LRDIMM/ 2,048GB
RDIMM 3DS/LRDIMM 3DS DDR4 memory. Leveraging advanced technology from
Intel
®
, the S7120 is capable of offering scalable 32 and 64-bit computing, high-
bandwidth memory design, and lightning-fast PCI-E bus implementation.
The S7120 not only empowers you in today’s demanding IT environment but also
offers a smooth path for future application upgradeability. All of these rich feature
sets provide the S7120 with the power and flexibility to meet demanding
requirements for today’s IT environments.
Remember to visit the TYAN
®
website at http://www.tyan.com. There you can find
all the information on all TYAN
®
products as well as all the supporting documentation,
FAQs, Drivers and BIOS upgrades.
1.2 Hardware Specifications
S7120GM2NRE Specifications
Processor
Q'ty / Socket Type
(2) LGA4189
Supported CPU
Series
Intel Xeon Scalable Processor,
3rd Gen Intel Xeon Scalable
Processor
Thermal Design
Power (TDP) Wattage
Max up to 270W
System Bus
Up to 11.2/10.4 GT/s with Intel
UltraPath Interconnect (UPI)
support
Chipset
PCH
Intel C621A
Memory
Supported DIMM
Qty
(8)+(8) DIMM slots
DIMM Type / Speed
DDR4 ECC RDIMM/RDIMM
3DS/LRDIMM/LRDIMM 3DS 3200
Capacity
Up to 1,024GB RDIMM/ 2,048GB
LRDIMM/ 2,048GB RDIMM
3DS/LRDIMM 3DS *Follow latest
Intel DDR4 Memory POR
Memory channel
8 Channels per CPU
