5
Memory voltage
1.2V
Expansion Slots
PCI-E
(2) PCI-E Gen4 x8,
(3) PCI-E Gen4 x16
LAN
Q'ty / Port
(2) GbE ports,
(1) GbE port dedicated for IPMI
PHY
Realtek RTL8211E
Storage
SATA
Connector
(3) Mini-SAS (12 ports) +
(2) SATA (totally support
14 ports)
Controller
Intel C621A
Speed
6Gb/s
RAID
RAID 0/1/10/5 (Intel
RSTe)
NVMe
Connector (M.2)
(2) 22110/2280 (by PCI-
E interface)
Graphic
Connector type
D-Sub 15-pin
Resolution
Up to 1920x1200
Chipset
Aspeed AST2600
Input /Output
Others
(1) ID button
USB
(2) USB3.0 ports (@ rear)
COM
(2) headers
VGA
(1) D-Sub 15-pin VGA port (@ rear)
RJ-45
(2) GbE ports,
(1) GbE dedicated for IPMI
Front Panel
(1) 2x12-pin SSI front panel header
SATA
(3) Mini-SAS HD from PCH SATA-III
Power
SSI 24-pin + 8-pin + 8-pin power
connectors
TPM (Optional)
TPM Support
Please refer to our TPM supported
list.
System Monitoring
Chipset
Aspeed AST2600
Fan
Total (5) 4-pin headers
Temperature
Monitors temperature for CPU &
memory & system environment
Voltage
Monitors voltage for CPU, memory,
chipset & power supply
LED
Over temperature warning
indicator, Fan & PSU fail LED
indicator
