8
USB
(2) USB 2.0 ports (@ rear)
COM
(2) headers
VGA
(1) D-Sub 15-pin VGA port (@ rear)
RJ-45
(2) 10GbE ports,
(1) GbE dedicated for IPMI
Front Panel
(1) 2x12-pin SSI front panel header
SATA
(3) Mini-SAS HD from PCH SATA-III
Power
SSI 24-pin + 8-pin + 8-pin power
connectors
TPM (Optional)
TPM Support
Please refer to our TPM supported
list.
System Monitoring
Chipset
Aspeed AST2600
Fan
Total (5) 4-pin headers
Temperature
Monitors temperature for CPU &
memory & system environment
Voltage
Monitors voltage for CPU, memory,
chipset & power supply
LED
Over temperature warning
indicator, Fan & PSU fail LED
indicator
Others
Watchdog timer support
Server Management
Onboard Chipset
Onboard Aspeed AST2600
AST2500 iKVM
Feature
24-bit high quality video
compression, Supports storage over
IP and remote platform-flash, USB
2.0 virtual hub
AST2500 IPMI
Feature
IPMI 2.0 compliant baseboard
management controller (BMC),
10/100/1000 Mb/s MAC interface
BIOS
Brand / ROM size
AMI, 32MB
Feature
Hardware Monitor, SMBIOS
3.0/PnP/Wake on LAN, Boot from
USB device/PXE via LAN/Storage,
User Configurable FAN PWM Duty
Cycle, Console Redirection, ACPI
sleeping states S4,S5, ACPI 6.1
Physical Dimension
Form Factor
SSI EEB compatible
Board Dimension
12.2” x 13.04” (309.8 x 331.2mm)
Regulation
FCC (DoC)
Class A
CE (DoC)
Class A
