EIL/MAN/002: REVISION 6 Date: July 2007 Page 25
USB (Universal Serial Bus) Interface Wiring
The table below provides the contact terminating assignments by number and electrical value
for the cable connectors.
Contact Number Signal Name Typical Wiring Assignment
1 VBUS Red
2 D- White
3 D+ Green
4 GND Black
Shell Shield Drain Wire
You can refer to the Universal Serial Bus Specification for details regarding this interface.
