Internet Alarm Communicator Installation Manual
NOTE: If this option is OFF, the yellow status LED on the communicator will indicate ‘Panel
Supervision Trouble’ (2 flashes) and the unit can not be programmed via the PC-LINK
cable.
NOTE: Account number in communicator section [851][021] automatically syncs with panel sys-
tem account number in section [310][000].
3. In panel sections [300] ‘Panel/Receiver Communications Paths’ subsections [001] to [004],
program the subsection with 02 to 04.
NOTE: Refer to panel reference manual for additional information
4. In panel section [350] ‘Communication Formats’, program the communication format as: CID
(03) or SIA FSK (04).
5. In panel sections [311] - [318] ‘Partition Call Directions’, program the call direction options for
the system.
6. In panel section [401] ‘DLS/SA Options’, set toggle option [2] ‘User Enable DLS’ to ON in
order to perform panel DLS session through Ethernet.
NOTE: Before leaving the premises, the installer should verify all programmed communications
paths. See programming options section [851][901] to send immediate test transmissions.
NOTE: Sending test transmissions to receivers that are not programmed will generate FTC Trou-
ble.
Communicator Troubles displayed on a HS2016/2032/2064/2128
If the The HS2016/2032/2064/2128 panel encounters a communicator trouble, a trouble message
is displayed on the LCD keypad. For more information about the communicator trouble, press
[*][2] or refer to the event buffer. The log entry shows Fault or Restore for each of the following
events:
• Alt. Comm Ethernet Trouble/Restore
• Alt. Comm Fault/Restore
• Alt. Comm Receiver (1-2) Absent/Restore
• Alt. Comm Receiver (1-2) supervision Trouble/Restore
• Alt. Comm Receiver (1-2) FTC Trouble/Restore
NOTE: When Panel displays “Alternate Fault,” communicator programming is not accessible via
the keypad.
Table 4: Communicator Path Programming
Valu e Communication Method
02 Auto Routing
03 Ethernet 1
04 Ethernet 2
