DESCRIPTION
General construction
The transmission case, Clutch, Clutch Housing, Engine and Front Axle Support are bolted together to form a rigid unit.
Front Axle & Wheels
The 4WD front axle is a center-pivot, reverse Eliot type.
The front wheel drive mechanism is incorporated as a part of the axle.
The front wheel drive power is taken off the rear transmission and transmitted to the differential in the front axle where the power
is divided into right and left and to the respective final cases.
In the final cases, the transmitted revolution is reduced by the level gears to drive the front wheel.
The 4WD mechanism with level gears provides wider steering and greater durability.
Engine
The tractors are fitted with vertical, Water-cooled 4-cycle.
Clutch and Transmission
A single plate dry clutch is used on these tractors.
Tractors with IPTO(Independent Power Take Off) are fitted with hydraulic clutch assy.
The transmission Gear box has six forward speed & two reverse speeds with a high-low select lever.
Presently, TYM tractors are fitted with sliding gear and constant mesh type gears.
Brakes
TYM tractors are provided with independent disc brakes operated by two road travel.
A foot brake lever is fitted for parking.
