TYM T254NH - Universal Symbols

Some of the universal symbols have been shown below with an indication of their meaning
Engine speed (rev/minX100) Pressured-open slowly Corrosive substance
Hours, recorded Continuous variable Slow or minimum Setting
Engine coolant temperature Warning fast or maximum setting
Fuel level Hazard warning Transmission oil pressure
Engine Stop control Neutral Turn signal
Lights Fan Transmission oil temperature
Horn Power take off engaged Parking brake
Engine oil pressure Power take off disengaged Working lamp
Air filter Lift arm/raise Differential lock
Battery charge Lift arm/lower See operator’s manual
5. UNIVERSAL SYMBOLS
SAFETY
1-22
