3 - 5
▶
TACHOMETER
It displays the revolution of the engine or PTO shaft per
minute.
▶
HOUR METER
It indicates the total time of use.
The last digit indicates one tenth hours.
(decimal place) While the hour meter on the left most section
Tachometer
Hour meter
Coolant temperature lamp
Fuel gauge
is in operation, the lamp below it blinks.
▶
FUEL GAUGE
This indicates the amount of fuel while the main switch is in
the "ON” position.
F - Full
E - Empty
● Poor fuel quality can damage the engine. Make
sure to use only the specied genuine Diesel fuel.
● Use fuel for winter season in winter to enhance en-
gine starting performance.
Important
▶
COOLANT TEMPERATURE LAMP
This indicates the temperature of coolant while the main switch
is in the "ON" position.
If the needle is in the red "H" zone during driving, the coolant
is overheated.
In this case, stop driving and take any necessary action accord-
ing to the troubleshooting instructions.
To Next Page
