► ENGINE OIL FILTER
Using a lter wrench turn the lter anti clock-
wise to remove it. Lightly smear the rubber
seal on the new lter with oil to ensure, turn it
clockwise until the seal contacts the base and
then turn it another 2/3 turn to tighten it.
► FUEL FILTER
The fuel lter/water separator (if equipped) is
not usually supplied by Perkins.
The following test describes a typical fuel l-
ter/water separator.
Refer to the OEM information for further in-
formation in the fuel lter/water separator.
Turn the fuel supply valve (if equipped) to the
OFF position before performing this mainte-
nance. Place a tray under the fuel lter in order
to catch any fuel that might spill.
Clean up any spilled fuel immediately.
Fuel filter Water Separator(1
st
)
Fuel Filter(2
nd
)
Fuel Supply Pump
1. Close the fuel supply valve (if equipped).
2. Clean the outside of the fuel lter assembly.
Note: If the fuel lter element is mot
equipped with a drain, remove cap.
Remove the nylon insert in order to
reduce the lever of fuel in the fuel l-
ter element. A reduction in the level
of fuel in the fuel lter element will
help prevent fuel from being spilled
when the element is removed.
Notice: Do not use a tool in order to re-
move the fuel lter. Attempting to
remove the fuel lter with a lter
wrench or a lter strap could dam-
age the locking ring.
3. Hold fuel lter and rotate quick release
collar counterclockwise. Removed and
discarded.
