Never use the diff lock at high speed or on the road as this can cause roll over and injury.
Caution
▶
▶▶
▶ Front wheel drive lever (4WD shift Lever)
In the ON position the front wheels are engaged and in
the OFF position they are disengaged.
Engage & disengage the front wheel drive with the front
wheels in the straight position and at low Engine RPM.
▶
▶▶
▶ Front wheel drive Button (4WD Button) – If Equipped
The Front wheel drive is ON when push the button.
And again push the button, it is operated OFF mode.
Do not use front wheel drive at high
44
Use of front wheel drive improves traction performance.
▶Driver’s seat
To adjust the seat backwards and forwards lift the
lever at the front of the seat and set it to the
desired position
▶ Tilt pedal
To adjust the inclination of the steering wheel with a 3 stages
and set it to the desired position.
important
Always use the clutch when using
the front wheel drive lever.
important
