9
6. SETTINGS AND OPERATION
SPLIT SCREEN
If you purchase one set of Solar
Powered Backup Camera with 6.8”
Widescreen HD Monitor (BT57132)
and extra Solar Powered Backup
Camera (BT56780), you can tap on
the Split Screen icon to switch
between dierent screen modes
after you pair the extra camera with
the Dash Monitor.
BATTERY INDICATOR
The battery indicator shows the
battery level of the Solar Wireless
Backup Camera.
NOTE: Fully charge and test the
camera before operation.
NOTE: Other than BT57132 and
BT56780, DO NOT pair this monitor
with other Type S backup cameras.
The 6.8” Motion Activated HD Monitor contains touch panel; all the operations can be done by tapping
and swiping on the monitor screen. Tap on the Tips icon for on-screen instructions. Push the power
button on the side to turn o the Dash Monitor while driving. NOTE: Please remember to turn the Dash
Monitor back on once the vehicle is stopped and ready to reverse.
Power
Button
