EasyTravel – ET1B User’s Manual Rev. 0708 23
11. DISPOSAL AND RECYCLING
The packing material must be separated to plastic and pa-
per/cardboard components and submitted to authorized recycling lo-
cations.
The EasyTravel device consists of electronic components, cables,
plastic parts, steel and aluminium frame and adapter parts. Do not
discard of any components to normal garbage facilities. When
EasyTravel is no longer operational, it is to be dismantled and sepa-
rated into above material groups and submitted to authorized recy-
cling facilities.
12. TECHNICAL DATA
*The actual range depends on the operation conditions and the load
Speed Continuously adjustable, up to 6 km/h (3.7 mph)
Power Supply 24 V from Two rechargeable maintenance-free
Sealed Lead/acid batteries
Standard size: 12V – 7.2 Ah
Jumbo size: 12V-12 Ah
Charging time 7 – 10 hours
Max. admissible slope 6
o
(10 %)
Max. negotiable curb
height
5 cm / 2”
Range approx.* Standard battery 6.5 - 8 km / 4 - 5 Miles
Jumbo battery 11 – 13 km / 6.5 – 8 Miles
Tires Flat-free PU 200 x 50
Dimensions: 57 X 104 X 86 cm / 22”X41”X34”
Weights:
Rear frame 12.9 Kg / 28.5 Lb
Front column (without
battery)
8.6 Kg / 19 Lb
Battery Pack Standard: 6.5 Kg / 14.5 Lb.
Jumbo: 9.2 Kg. / 20.2 Lb.
Total weight 28 Kg / 62 Lb.
Maximum users weight 114 Kg. / 250 lb.
