ZED-F9P-Integration manual
Pin No Name I/O Description
9 Reserved - Reserved
10 Reserved - Reserved
11 Reserved - Reserved
12 GND - Ground
13 Reserved - Reserved
14 GND - Ground
15 Reserved - Reserved
16 Reserved - Reserved
17 Reserved - Reserved
18 Reserved - Reserved
19 GEOFENCE_STAT O Geofence status, user defined
20 RTK_STAT O RTK status: 0 (RTK fixed), Blinking (receiving and using RTCM corrections), 1
(otherwise)
21 Reserved - Reserved
22 Reserved - Reserved
23 Reserved - Reserved
24 Reserved - Reserved
25 Reserved - Reserved
26 RXD2 I Correction UART input
27 TXD2 O Correction UART output
28 Reserved - Reserved
29 Reserved - Reserved
30 Reserved - Reserved
31 Reserved - Reserved
32 GND - Ground
33 VCC I Voltage supply
34 VCC I Voltage supply
35 Reserved - Reserved
36 V_BCKP I Backup supply voltage
37 GND - Ground
38 V_USB I USB supply
39 USB_DM I/O USB data
40 USB_DP I/O USB data
41 GND - Ground
42 TXD / SPI_MISO O Host UART output if D_SEL = 1(or open). SPI_MISO if D_SEL = 0
43 RXD / SPI_MOSI I Host UART input if D_SEL = 1(or open). SPI_MOSI if D_SEL = 0
44 SDA / SPI_CS_N I/O I2C Data if D_SEL = 1 (or open). SPI Chip Select if D_SEL = 0
45 SCL / SPI_CLK I/O I2C Clock if D_SEL = 1(or open). SPI Clock if D_SEL = 0
46 TX_READY O TX_Buffer full and ready for TX of data
47 D_SEL I Interface select for pins 42-45
48 GND - Ground
49 RESET_N I RESET_N
50 SAFEBOOT_N I SAFEBOOT_N (for future service, updates and reconfiguration, leave OPEN)
51 EXTINT I External Interrupt Pin
UBX-18010802 - R08
4 Design Page 72 of 110
